MACHINE DESCRIPTION:

Powerful, heavy-duty CNC turning center with (M) milling capability and (T) lower turret. Milling is achieved through a live rotary spindle in the machine's 12-position upper turret. The 8-position lower turret provides additional tooling capacity and enhanced machining operations. This Multi-Tasking machine allows for turning, milling, drilling and tapping, as well as deep boring up to 40", in single setup. Designed for large-diameter, long shaft workpieces, the CYBERTECH TURN 4500MT has the rigidity and horsepower for extremely aggressive metal removal.

With an ergonomic design, the CYBERTECH TURN 4500MT is highly visible, and part setups and programming are fast and easy. There is also an available pipe re-threading program option that calculates positions and performs re-threading in a few simple steps.

MACHINE CHARACTERISTICS:

• 12-position upper turret with rotary tool spindle and 8-position lower turret for simultaneous turning.
• Built-in premium threading function
• Deep hole boring with automatic changer
• Fully programmable servo driven tailstock
• Mazatrol conversational CNC and/or G code format
