MACHINE DESCRIPTION:

Powerful, heavy-duty CNC turning center with a 12-position upper turret and 8-position lower turret. Turning is achieved through the 12-position drum turret and a 8-position lower turret providing simultaneous turning for aggressive metal removal. This Multi-Tasking machine allows for facing, turning, grooving, threading applications as well as deep boring up to 40", in single setup. Designed for large-diameter metal billets and long shaft workpieces, the CYBERTECH TURN 5500T has the rigidity and horsepower for extremely aggressive metal removal.

With an ergonomic design, the CYBERTECH TURN 5500T is highly visible, and part setups and programming are fast and easy. There is also an available pipe re-threading program option that calculates positions and performs re-threading in a few simple steps.

MACHINE CHARACTERISTICS:

• 12-position upper turret and 8-position lower turret for simultaneous turning.
• 14.8" spindle bore is standard equipment
• Built-in premium threading function
• Deep hole boring with automatic changer
• Fully programmable servo driven tailstock
• Mazatrol conversational CNC and/or G code format
